Product Info
Ice Air concealed vertical fan coil FCVC unit is designed to accommodate large spaces where easy access to the equipment for maintenance purposes is preferred. Typically, the unit is located in a closet within the conditioned space.
Category: Vertical Concealed
Products: 5FCVC02, 5FCVC03, 5FCVC04, 5FCVC06, 5FCVC08, 5FCVC10, 5FCVC12
- FCVC: Vertical Concealed FCU – Product Sheet
- FCVC: Vertical Concealed FCU – Submittal
- FCVC: Vertical Concealed FCU – Dimensional Drawing
- FCVC/FCVE: Vertical FCU – Installation Manual
- FCVC/FCVE: Vertical FCU – Operating & Maintenance Manual
- FCU Product Line Brochure
- ICE AIR – Limited Warranty
* Available in 2-pipe and 4-pipe configurations


Specifications
MODEL | 5FCVC02 | 5FCVC03 | 5FCVC04 | 5FCVC06 | 5FCVC08 | 5FCVC10 | 5FCVC12 | |
Airflow (CFM) | HIGH | 200 | 300 | 400 | 600 | 800 | 1,000 | 1,200 |
---|---|---|---|---|---|---|---|---|
MED | 150 | 225 | 300 | 450 | 600 | 750 | 900 | |
LOW | 100 | 150 | 200 | 300 | 400 | 500 | 600 | |
Cooling Capacity (BTU/h) | HIGH | 6,900 | 8,100 | 11,600 | 18,700 | 20,800 | 30,700 | 34,100 |
MED | 5,175 | 6,075 | 8,700 | 14,025 | 15,600 | 23,025 | 25,575 | |
LOW | 4,140 | 4,860 | 6,960 | 11,220 | 12,480 | 18,420 | 20,460 | |
Heating Capacity (BTU/h) | HIGH | 10,350 | 12,150 | 17,400 | 28,050 | 31,200 | 46,050 | 51,150 |
MED | 7,760 | 9,110 | 1,305 | 2,100 | 23,400 | 34,540 | 38,360 | |
LOW | 6,200 | 7,300 | 10,450 | 16,800 | 18,700 | 27,600 | 30,650 | |
Fan | Type | Double Inlet Forward Curved | ||||||
Number | 1 | 1 | 2 | 2 | 2 | 3 | 4 | |
Motor | V/Hz | 115V/60Hz | ||||||
Coil | Type | Aluminum Fin and Copper Tube | ||||||
Piping Connections (in) | Inlet/Outlet | 1/2 | ||||||
Condensate | 5/8 | |||||||
Specification Notes: Cooling: 80°F DB, 67°F WB, 45°F Entering Water, 10°F Temperature Differential Heating: 70°F DB, 180°F Entering Water |
